BS081 - #81 Beltservice 2 Ply 220 3/16" x 1/16" Hot Asphalt SOR Conveyor Belt

$10.00 IS FOR A PRODUCT SAMPLE
-or-
REQUEST A FREE BELT ASSEMBLY QUOTE

Use [Add to cart] to purchase a sample piece of belting which will put a $10 credit on your account if you decide to order your belt from BeltSmart. Limit 3 per customer or $30.00 total. Product samples are shipped priority mail.

Use [Request a Laced or Endless Belt Quote] to have our customer service work up a quote with mechanical lace, open-ended, or vulcanized endless. Our team of belt specialists are on hand during regular business hours to answer questions and help with any questions you may have.

If you are unsure what your belting is and would like us to identify it, please send us a sample of the belting to the address given in our [about us] page. Include name, company, phone, address and dimensions to 1/8" for width and length.

Applications:
Heavy Duty Belting Oily Grains Hot Asphalt Foundries Machine Oils Oil Treated Coal
Features:
"Super Oil Resistant" is specially compounded for applications requiring moderate to very high oil resistance such as hot asphalt, foundries, oily grains, machine oils, and oil treated coal. These belts have the same high-qualtiy fabric characteristics as "Standard."

	2 Ply 220 3/16" x 1/16" Hot Asphalt SOR Pt No.: 81	3 Ply 330 3/16" x 1/16" Hot Asphalt SOR Pt No.: 81a
Thickness	3/8"	13/32"
Covers	3/16" x 1/16"	3/16" x 1/16"
Carcass	Synthetic
Working Tension per Inch Width	220 lbs.	330 lbs.
Approx. Weight Lbs. Per Inch Width	.200 lbs.	.250 lbs.
Min. Pulley Diameter Head	16"	18"
Min. Pulley Diameter Tail	10"	12"
Temperature Range	-10 deg. F / 300 deg. F
Compound	Nitrile
Lacing/Fastener Recommendations	Flexco Plate #190 Flexco Hinged #375 or #550 Flexco Rivet R5	Flexco Plate #190 Flexco Hinged #375 or #550 Flexco Rivet R5 1/2

SOR = Super Oil Resistant
