BS059B - #59b Beltservice 3 Ply 180 Tan Pure Gum Roughtop x Bare Conveyor Belt

$10.00
SKU 59b Beltservice

$10.00 IS FOR A PRODUCT SAMPLE
-or-
REQUEST A FREE BELT ASSEMBLY QUOTE

Use [Add to cart] to purchase a sample piece of belting which will put a $10 credit on your account if you decide to order your belt from BeltSmart. Limit 3 per customer or $30.00 total. Product samples are shipped priority mail.

Use [Request a Laced or Endless Belt Quote] to have our customer service work up a quote with mechanical lace, open-ended, or vulcanized endless. Our team of belt specialists are on hand during regular business hours to answer questions and help with any questions you may have.

If you are unsure what your belting is and would like us to identify it, please send us a sample of the belting to the address given in our [about us] page. Include name, company, phone, address and dimensions to 1/8" for width and length.

PRODUCT DESCRIPTION


Beltservice Corperation Belting - Incline Belting - Tan Rubber & Pure Gum Roughtop
Applications:
  • Incline/Decline Conveying
  • Sanding Machinery
Features:
  • Tan color is non-marking.
  • The genuine gum is soft durometer for highest grab, steepest inclines and long wear where required.
  • The tan rubber is more economical, yet highly serviceable.
  • Three and four ply bare bottom construction is popular for sanding machinery applications.
3 Ply CP 30 Tan
Rubber
Roughtop x FS
Pt No.: 58
3 Ply CP 30 Tan
Genuine Pure Gum
Roughtop x FS
Pt No.: 59
2 Ply 160 Tan
Pure Gum
Roughtop x Bare
Pt No.: 59a
3 Ply 180 Tan
Pure Gum
Roughtop x Bare
Pt No.: 59b
4 Ply 240 Tan
Pure Gum
Roughtop x Bare
Pt No.: 59c
3 Ply 225 Tan
Pure Gum
Roughtop x Bare
Pt No.: 60a
3 Ply 225 Tan
Rubber
Roughtop x Bare
Pt No.: 60b
Thickness 5/16" 5/16" 9/32" 5/16" 23/674" N/A N/A
Covers Roughtop x FS Roughtop x FS Roughtop x Bare Roughtop x Bare Roughtop x Bare Roughtop x Bare Roughtop x Bare
Carcass 32 oz. CN40 32 oz. CN40 Polyester Polyester Polyester N/A N/A
Working Tension
per Inch Width
90 lbs. 90 lbs. 160 lbs. 180 lbs. 240 lbs. N/A N/A
Approx. Weight
Lbs. Per Inch Width
.104 lbs. .090 lbs. .104 lbs. .110 lbs. .120 lbs. N/A N/A
Min. Pulley Diameter 2-1/2" 2" 3" 4" 8" N/A N/A
Temperature Range -40 deg. F / 250 deg. F
Clipper Lace #1 #1 #1 #2 #2 N/A N/A
Alligator Lace #7 #7 #1 #7 #15 N/A N/A
Alligator Staple #125 #125 #125 #125 #125 N/A N/A
FS = Friction Surface
